ET-536A series：SMD
Power Inductors.
- Unshielded drum core .
- Height：5.46m/m Max ( 5.97m/m Max
for 1.0~10uH )
( 5.72m/m Max for 15 ~ 100uH ).
- Footprint： 9.91x13.21m/m Max.
- Current rating： Up to 10A.
- Inductance range： 1.0uH to 2.2mH.
|
|
|
ET-529 series: SMD Shielded Power Inductors.
- High inductance. High DC current capability.
- True surface mount design.
- Tape & Reel packaging standard, 3000pcs per
13" Reel.
- Magnetically shielded.
- RoHS compliant component.
|
|
|
ET-49160 seriess：
Gate Drive Transformers for EP Type.
- Operating Temperature from -40
 to 130.
- Manufactured to UL recognized 155 insulation sysem.
- Materials meet flammability requirements for UL
94V-0.
|
|
|
ET-52300A series：AC
Line Filters EMI/RFI
Common Mode Choke ( SMD Type ).
- Prevents noise emission, such as electromagnetic
interference (EMI) & radio frequency interference (RFI).
- Protects AC side from the effects of switching
regulators.
- Wide range of available inductances and current
ratings.
|
|
|
ET-52600 series： Surface mount common mode
choke.
- Mechanical configuration
A flat top surface mount case with excellent coplanarity of terminals.
- Operating temperature Range 0 to +150.
- Withstanding voltage：
500VAC.
- Rated RMS current based upon 40 temperature rise from 25 ambient.
- Maximum power
dissipation at 25 0.605 watts.
|
|
|
ET-52700
series：
Common mode choke for DC line.
- Idea for dc line and countermeasure against radiation
noise.
- Low height and small size SMD.
- Excellent frequency characteristics.
|
|
|
ET-52800
series：
Noise countermeasures common mode choke
- Use new material for higher impedance under high
frequency range noise suppression.
- This series employs two outer magnetic path limbs
design with windings on the center magnetic path limb of double-square
shaped closed magnetic circuit ferrite core to reduce leakage flux.
- Wide range of available inductances and current
ratings.
|
|
|
ET-52900 series： High Current Inductor
- Highest inductance with a low number of turns.
- Lowest DCR, Lower loss.
- Winding to winding isolation 3000 Vrms
for 1 sec.
- Turn ratio 1 : 1 : 1.
|
|
|
ET-53000 series： High Current Inductor
- Ideal for audio playing systems.
- Larger ferrite drum can attain a higher Q than other
typical SMD coils.
- This will result in larger inductances, maintain high
magnetic saturation for large signals and maintain low distortion of
signals.
- This type also has electromagnetic shielding for low
ENI.
- Base can accommodate up to two internal capacitors.
- Reflows at 235 ~ 245 ( 5-10 secs
max ).
|
|
|
ET-72300C series： SMD Current Sense
Transformer
- Low profile - height 4.1 mm max.
- Designed for automatic pick and place.
- Operating frequency range 10KHz
to 1MHz.
- Primary rated for 20 Amps AC ms
max.
- Special design av ailable on customer request.
|
|
|
|
|
